Choosing a periodic method: GDF, BIPOLE, and GPW / GAPW¶

A molecular calculation has exactly one way to build the Coulomb (and exchange) matrices. A periodic one has a choice, because the bare lattice sum of \(1/r\) over an infinite crystal diverges, and there is more than one good way to tame it. This page is the map: what the routes are, how to switch between them with a single keyword, and how to pick the right one.

Route status at a glance

The labels below follow Methods: theory and status.

Route (`jk_method=`)	Status
`"gdf"`	production for Gamma and multi-k RHF, RKS, UHF, UKS in 3-D (a 1-D wire is modelled as a 3-D cell with transverse vacuum; `dim=1` is refused) and the bounded closed-shell 2-D slab route; periodic ROHF on GDF is a preview
`"bipole"`	production energies and finite-difference forces (Gamma and multi-k RHF, UHF, RKS, UKS, 3-D); analytic gradients are a preview; the quartet multipole far field is gated
`"gpw"`	production within its shipped envelope (Gamma RHF, UHF, RKS, UKS; multi-k pure-DFT RKS, ROKS, UKS; Gamma analytic gradients; DFT+U; D3-BJ); GPW ROHF/ROKS are a preview; the `.out` route line carries an experimental tag and the grid infrastructure emits `GAPWExperimentalWarning` once per grid build while the GPW/GAPW family is completed
`"gapw"`	experimental
`"rijcosx"`	experimental
`"auto"` on a `dim=2` slab (SLAB_EWALD_2D)	production for RHF, RKS and UKS
`method="aiccm"` with any `variant`	experimental

One system, several routes¶

You select the route with the jk_method keyword on run_periodic_job. The system, basis, and method stay the same, only the Coulomb engine underneath changes:

import vibeqc as vq
# ... define `system` (a PeriodicSystem) and `basis` ...

# Production default for closed-shell RHF / RKS (Gamma or multi-k):
res = vq.run_periodic_job(system, basis, method="RKS", functional="pbe",
                          kpoints=[4, 4, 4], jk_method="gdf")

# BIPOLE: the Ewald J-split route (open shell, hybrids, CRYSTAL14 cross-validation):
res = vq.run_periodic_job(system, basis, method="RKS", functional="pbe",
                          kpoints=[4, 4, 4], jk_method="bipole")

# Plane-wave routes: GPW is production within its envelope, GAPW is experimental.
res = vq.run_periodic_job(system, basis, method="RKS", functional="pbe",
                          jk_method="gpw")    # or jk_method="gapw"

# Independent finite cyclic-cluster RHF/RKS (experimental):
res = vq.run_periodic_job(system, basis, method="RKS", functional="pbe0",
                          jk_method="aiccm2026dev-b",
                          aiccm_lattice_extension=[4, 4, 4],
                          aiccm_backend="rijcosx")

If you omit jk_method (or pass "auto"), vibe-qc chooses for you. It branches on dimensionality first: a dim=2 slab always goes to SLAB_EWALD_2D, the vacuum-free 2D Ewald gauge, and every bulk route raises there. Otherwise it is GDF for closed-shell RHF/RKS and BIPOLE for open-shell UHF/UKS. The default is already a production-quality route; you reach for this page when the default is not the one you want. (Open-shell GDF also ships and is reachable with an explicit jk_method="gdf"; AUTO keeps BIPOLE as the open-shell default by design.)

The routes¶

GDF, Gaussian density fitting. The production default for closed-shell HF and KS, at \(\Gamma\) and at a full k-mesh, with open-shell UHF / UKS available too (Gamma and multi-k). It projects the AO pair density onto a charge-compensated auxiliary basis, which cancels the divergent monopole at the source and leaves a finite, fast Coulomb metric (Sun, Qiming, Berkelbach, Timothy C., et al. (2017). *Gaussian and plane-wave mixed density fitting for periodic systems.* Journal of Chemical Physics, **147**(16), 164119. doi:[10.1063/1.4998644](https://doi.org/10.1063/1.4998644)). Best all-round choice for ionic and covalent insulators. Deep dive: density_fitting.md.

BIPOLE, an Ewald J-split. Splits \(1/r\) into a short-range piece summed in real space and a long-range piece summed in reciprocal space (Ewald, Paul Peter (1921). *Die Berechnung optischer und elektrostatischer Gitterpotentiale.* Annalen der Physik, **369**(3), 253-287. doi:[10.1002/andp.19213690304](https://doi.org/10.1002/andp.19213690304)), sharing a single Ewald parameter across the electron-nucleus, electron-electron, and nucleus-nucleus terms, with the Gaussian-density electrostatics of Saunders, V. R., Freyria-Fava, C., et al. (1992). *On the electrostatic potential in crystalline systems where the charge density is expanded in Gaussian functions.* Molecular Physics, **77**, 629–665. doi:[10.1080/00268979200102671](https://doi.org/10.1080/00268979200102671) and the CRYSTAL conventions of Dovesi, R., Orlando, R., et al. (2014). *CRYSTAL14: A program for the ab initio investigation of crystalline solids.* International Journal of Quantum Chemistry, **114**, 1287–1317. doi:[10.1002/qua.24658](https://doi.org/10.1002/qua.24658). This is the route for open-shell systems, hybrid functionals at multiple k-points, and cross-validating against a CRYSTAL14 reference. Production for 3D; the multi-k corrected-gauge exchange is an active frontier. Deep dive: bipole.md.

GPW, Gaussian + plane-wave (Lippert, Gerald, Hutter, Jürg, and Parrinello, Michele (1997). *A hybrid Gaussian and plane wave density functional scheme.* Molecular Physics, **92**(3), 477-487. doi:[10.1080/00268979709482119](https://doi.org/10.1080/00268979709482119)). Carries the density on a uniform grid and solves the Poisson equation by FFT (an \(\mathcal{O}(N_g\log N_g)\) Hartree build), pinning the \(\mathbf{G}=0\) component to zero for a neutral cell. It is production within its shipped envelope: \(\Gamma\)-point RHF, RKS, UHF, and UKS plus multi-k pure-DFT RKS, ROKS and UKS, with Gamma analytic forces, the finite-difference Hessian, DFT+U, smearing, and D3(BJ) dispersion; GPW ROHF and ROKS are a maintained preview. It carries an all-electron density on the grid, so no pseudopotential files are involved. The .out route line still carries an experimental tag and the plane-wave grid infrastructure emits GAPWExperimentalWarning once per grid build while the GPW/GAPW family is completed; GDF and BIPOLE are the longer-validated routes. Deep dive: gapw.md.

GAPW, Gaussian-augmented plane-wave (Lippert, Gerald, Hutter, Jürg, and Parrinello, Michele (1999). *The Gaussian and augmented-plane-wave density functional method for ab initio molecular dynamics simulations.* Theoretical Chemistry Accounts, **103**(2), 124-140. doi:[10.1007/s002140050523](https://doi.org/10.1007/s002140050523), Krack, Matthias and Parrinello, Michele (2000). *All-electron ab-initio molecular dynamics.* Physical Chemistry Chemical Physics, **2**(10), 2105-2112. doi:[10.1039/b001167n](https://doi.org/10.1039/b001167n)). GPW plus a per-atom radial augmentation that sharpens all-electron accuracy by splitting the Hartree potential into a smooth grid part and a hard atomic correction. Experimental: molecular-limit Gamma HF and block-construction DFT ship, compact-crystal augmentation validation is pending, and the library drivers emit GAPWExperimentalWarning. Deep dive: gapw.md.

RIJCOSX, density-fitted J plus chain-of-spheres K. Builds the Coulomb matrix by GDF density fitting and the exchange by a seminumerical chain-of-spheres (COSX, Neese, Frank, Wennmohs, Frank, et al. (2009). *Efficient, approximate and parallel Hartree-Fock and hybrid DFT calculations. A ‘chain-of-spheres’ algorithm for the Hartree-Fock exchange.* Chemical Physics, **356**(1–3), 98–109. doi:[10.1016/j.chemphys.2008.10.036](https://doi.org/10.1016/j.chemphys.2008.10.036)) sum on a periodic Becke grid. It runs a full \(\Gamma\)-point RHF SCF today and true multi-k RHF, RKS, UHF, and UKS on uniform time-reversal-symmetric meshes through the GDF/COSX backend. The dedicated \(\Gamma\) route is at parity with GDF for vacuum-padded (molecular-limit) cells; its tight-cell exchange K is still being brought to GDF parity, so use GDF for production tight-cell hybrids meanwhile. Periodic RIJCOSX is experimental. Deep dive: density_fitting.md.

Note

The plane-wave routes are vibe-qc’s own grid / Gaussian-augmented implementation. GPW and GAPW are computed entirely by vibe-qc’s own kernels (GAPW is the all-electron variant, a hard/soft Gaussian density partition rather than the projector-augmented-wave method), and the ASE Calculator and command-line interface mirror GPAW’s so a GPAW user is at home. The separate external GPAW code is used only as an out-of-process parity reference; vibe-qc never imports it or calls it to compute an energy.

Note

Beyond the k-point routes: the cyclic cluster model (CCM). vibe-qc’s signature periodic approach is real-space rather than reciprocal-space: the cyclic cluster model treats a crystal as a single finite cyclic cluster rather than sampling the Brillouin zone (Bredow, Thomas, Geudtner, Gerald, and Jug, Karl (2001). *Development of the cyclic cluster approach for ionic systems.* Journal of Computational Chemistry, **22**(1), 89–101. doi:[10.1002/1096-987X(20010115)22:1<89::AID-JCC9>3.0.CO;2-7](https://doi.org/10.1002/1096-987X(20010115)22:1<89::AID-JCC9>3.0.CO;2-7), Peintinger, Michael F. and Bredow, Thomas (2014). *The cyclic cluster model at Hartree-Fock level.* Journal of Computational Chemistry, **35**(11), 839–846. doi:[10.1002/jcc.23550](https://doi.org/10.1002/jcc.23550)). It is available today at the semi-empirical (MSINDO) level; two distinct experimental ab-initio CCM approaches ship separately - Γ-CCM / aiccm2026dev-a (union-and-weight/ Wigner-Seitz integral weighting) and χ-CCM / aiccm2026dev-b (finite-translation-group characters; 3-D only) - and are under active head-to-head study. No cross-approach delta is currently reportable. See the CCM tutorial and the CCM reference.

How to choose¶

All of these target the same periodic Hamiltonian, but their total energies agree only once the finite Coulomb and exchange-divergence conventions are matched (see Running a real comparison, whose MgO GDF and BIPOLE pair differs by about 0.5 Ha). They differ in cost, in which methods they support, and in maturity. Pick by your situation:

Your situation	Route	Why
Closed-shell RHF / RKS, \(\Gamma\) or multi-k	GDF (default)	fastest production route; chemical accuracy on insulators
Open-shell UHF / UKS	BIPOLE (AUTO default) or GDF	both run open-shell \(\Gamma\) + multi-k; AUTO keeps BIPOLE
Full-range hybrid at multiple k-points	BIPOLE or RIJCOSX	both carry exact-exchange K at \(\mathbf{k}\neq 0\); RIJCOSX uses the composed COSX backend
Cross-validating against CRYSTAL	BIPOLE	the shared-\(\alpha\) Ewald J-split gives directly comparable energies
Tight ionic crystal at \(\Gamma\)	GDF	auxiliary fit avoids grid / Ewald overhead
Plane-wave Hartree-J, large smooth-density cell	GPW	smooth-grid FFT-Poisson Hartree; \(\Gamma\) RHF/RKS/UHF/UKS + multi-k pure-DFT RKS/ROKS/UKS (production within that envelope)
Plane-wave with all-electron augmentation	GAPW	per-atom augmentation, no pseudopotential files (experimental)
Seminumerical exchange at \(\Gamma\) or uniform multi-k	RIJCOSX	GDF-J + chain-of-spheres COSX-K; use GDF for tight-cell \(\Gamma\) hybrids

Important

The automatic default (GDF for closed-shell, BIPOLE for open-shell) already covers closed- and open-shell work, and both are the longer-validated production routes. GPW is production within its envelope and is reached by an explicit jk_method="gpw"; GAPW and RIJCOSX also run a full SCF today but are experimental (RIJCOSX has multi-k coverage, but its dedicated \(\Gamma\) tight-cell exchange is not yet at GDF parity). For a \(\Gamma\)-point hybrid functional on a tight ionic crystal, stay on GDF or BIPOLE until that gap closes.

Running a real comparison¶

The honest way to compare routes is to run the same crystal through more than one and watch the total energy land on the same value after the finite Coulomb and exchange-divergence conventions are matched. Then they are different engines for the same declared Hamiltonian, so any disagreement beyond the fitting/grid tolerance is a bug, not a feature.

Good starting points, all with verified reference output you can diff against:

The periodic foundations: periodic_hf and periodic_dft.
A full multi-k walkthrough on the default GDF route: lih_multi_k and lih_pob_tzvp_solid_state.
A current MgO route fixture: bundle README, GDF input, GDF .out, GDF .qvf, BIPOLE .out, BIPOLE .qvf, and vibe-view captures. The GDF run converged in 14 iterations to -271.7175700123166 Ha per primitive cell on a 2 x 2 x 2 Monkhorst-Pack mesh. The symmetry-reduced BIPOLE run converged in 23 iterations to -271.21454466172247 Ha per primitive cell. The bundle is useful for inspecting route-specific inputs, logs, QVFs, and viewer output; do not read this pair as a GDF/BIPOLE parity assertion.
The runnable scripts under examples/periodic/ (LiH, MgO, NaCl, and more); change jk_method and re-run to compare the routes.

For the k-space machinery every periodic route shares (the Brillouin zone, Bloch phase, and why a k-mesh is needed at all), read kpoints_brillouin_bloch.
